Tripod Picatinny Interface
Std 1913 Picatinny Interface for mounting of Monoculars
MINI LRF 50
POWERFUL. INSTANT. EFFECTIVE.
TARSIER MINI LRF 50
POWERFUL. INSTANT. EFFECTIVE.
Elevate your assault missions with the TARSIER-MINI 50, the ultimate advanced thermal scope sight. Designed for precision, it ensures accurate target acquisition while maintaining exceptional portability and combat readiness. Equip yourself with the TARSIER-MINI 50 and experience unmatched performance in tactical engagements.
LRF
Built in Laser Range Finder Opt:1/3 km
Convenient Power
Power up the sight with 2x CR123 Batteries
Exceptional Range
Detect Vehicle Size Targets up to 2600 meters
Experience High Quality
12µm 640 x 480 Sensor for an amazing view & clarity
Weapon Mountable
Easy mounting on small arms with Picatinny Rail
Light Weight & Ergonomic
Weighs less than 700 grams
Explore
TARSIER MINI LRF 50
Special Features
White Hot View
In White Hot mode, warmer objects appear brighter against cooler surroundings, giving you a crisp and intuitive thermal picture. This view is ideal for quick detection, target tracking, and scanning wide areas with maximum contrast.
Black Hot View
Black Hot mode displays heat signatures as darker shades, making it easier to identify shapes, terrain details, and human silhouettes. This is especially effective in high-temperature environments and long-range target observation.
APPLICATIONS
- Tactical Ops
- Reconnaissance
- Surveillance
- Situation Awareness
- Force Protection
- Martine Surveillance
- Facility Protection
- Search & Rescue
- Border Patrol
- Counter Insurgency
Specifications
TARSIER MINI LRF 50
TARSIER MINI LRF 50
| PRODUCT | TARSIER MINI 50 | |
| SENSOR | Type | Uncooled |
| Detector Resolution (Pixels) | 640 × 480 | |
| Pixel Pitch | 12µm | |
| NETD | ≤ 40mK | |
| Spectral Band | 8–12µm | |
| Frame Rate | 30Hz | |
| OPTICS | Objective Lens | 50mm |
| F Number | 1.2 | |
| Digital Magnification | 1×, 2×, 4× | |
| Optical Magnification | 2.8× | |
| Field of View (HxV) | 8.8° × 6.6° | |
| Diopter Adjustment Range | 2 to -6 | |
| DISPLAY | Type | OLED |
| OLED Resolution (Pixels) | 640 × 480 | |
| RANGE PERFORMANCE | Detection Range (Human) | 1600 m |
| Recognition Range (Human) | 700 m | |
| Identification Range (Human) | 350 m | |
| Detection Range (Vehicle) | 2800 m | |
| Recognition Range (Vehicle) | 1200 m | |
| Identification Range (Vehicle) | 500 m | |
| PHOTO / VIDEO RECORDER | Video Recording (In-Built) | Yes |
| Image Storage (In-Built) | Yes | |
| Image Storage Qty (In-Built) | 128 Images | |
| Video Rec Duration (In-Built) | 15 min | |
| WI-FI | Wireless Connectivity | Optional |
| Mobile Application | Optional | |
| ENVIRONMENTAL CHARACTERISTICS | Operating Temperature Range | -35°C to +55°C |
| Storage Temperature Range | -40°C to +60°C | |
| STD for Shock & Vibration | MIL-STD-810G | |
| Water Immersion | 1m – 30 min, dT = 27°C | |
| LRF | LRF Eye Safety Class | Class 1 / 1M |
| LRF Range | 1 / 3 km | |
| COMPATIBILITY | Standard Mount Name | MIL STD 1913 |
| Mounting Type | Picatinny Rail | |
| POWER SUPPLY | Battery Type | CR123 |
| Battery Time (Rechargeable) | 4.5 hrs | |
| External Power Input | Yes | |
| START UP TIME | Startup Time | ≤ 6 sec |
| DIMENSIONS | Dimension | 192.1 × 54 × 74.60 mm |
| WEIGHT | Weight (Complete) | < 0.8 kg |
| Weight (Sight Only) | < 0.750 kg |
Accessories
Tripod
Universal interface tripod for use in mounted position for long observation
Solar Battery Charger
Foldable solar charger to charge AA Batteries / Power Bank
