TARSIER Clip-On
Compact Build. Combat Clarity
TARSIER clip-on
Level Up Your Thermal Edge.
Enhance your battlefield optics with the TARSIER Clip-On, a compact, mission-ready thermal augmentation system engineered for
seamless integration. Built for tactical adaptability, it transforms standard day sights into high-performance thermal platforms without
sacrificing accuracy or mobility. Deploy the TARSIER Clip-On to achieve rapid target acquisition, uncompromised clarity, and full-spectrum
operational agility—any mission, any environment.
Experience High Quality
12µm 640 x 480 Sensor for an amazing view & clarity
Picatinny Rail Compatible
Easy mounting on small arms with Picatinny Rail
Exceptional Range
Detect Vehicle Size Targets up to 2600 meters
Light Weight & Ergonomic
Weighs less than 700 grams
Explore
TARSIER clip-on
Special Features
White Hot View
In White Hot mode, warmer objects appear brighter against cooler surroundings, giving you a crisp and intuitive thermal picture. This view is ideal for quick detection, target tracking, and scanning wide areas with maximum contrast.
Black Hot View
Black Hot mode displays heat signatures as darker shades, making it easier to identify shapes, terrain details, and human silhouettes. This is especially effective in high-temperature environments and long-range target observation.
Designed to mount directly onto Picatinny rails, enabling rapid deployment without altering your existing zero.
Equipped with a 12µm 640×480 sensor to deliver sharp, reliable visuals in complex environments.
Provides long-range detection performance—up to 2800m for vehicles—ensuring strong situational awareness.
Seamless Optic Integration
Specifications
| PRODUCT | TARSIER CLIP-ON | |
| SENSOR | Sensor Type | Uncooled |
| Detector Resolution | 640 × 480 pixels | |
| Pixel Pitch | 12µm | |
| NETD | ≤ 40 mK | |
| Spectral Band | 8–12µm | |
| Frame Rate | 30 Hz | |
| OPTICS | Objective Lens | 50mm |
| F Number | 1.2 | |
| Digital Magnification | 1×, 2×, 4× | |
| Optical Magnification | 2.8× | |
| Field of View | 8.8° × 6.6° | |
| Diopter Adjustment | +2 to -6 | |
| DISPLAY | Display Type | OLED |
| OLED Resolution | 640 × 480 pixels | |
| RANGE PERFORMANCE | Detection Range (Human) | 1600 m |
| Recognition Range (Human) | 700 m | |
| Identification Range (Human) | 350 m | |
| Detection Range (Vehicle) | 2800 m | |
| Recognition Range (Vehicle) | 1200 m | |
| Identification Range (Vehicle) | 500 m | |
| PHOTO / VIDEO RECORDER | Video Recording | Yes (In-Built) |
| Image Storage | Yes (In-Built) | |
| Image Capacity | 128 Images | |
| Video Duration | 15 minutes | |
| CONNECTIVITY | Wi-Fi | Optional |
| Mobile Application | Optional | |
| ENVIRONMENTAL | Operating Temperature | -35°C to +55°C |
| Storage Temperature | -40°C to +60°C | |
| Shock & Vibration | MIL-STD-810G | |
| Water Immersion | 1m – 30 min | |
| COMPATIBILITY | Mount Standard | MIL-STD-1913 |
| Mount Type | Picatinny Rail | |
| POWER SUPPLY | Battery Type | CR123 |
| Battery Time | 4.5 hours | |
| External Power Input | Yes | |
| GENERAL | Startup Time | ≤ 6 sec |
| Dimensions | 192.1 × 54 × 74.6 mm | |
| Weight (Complete) | < 0.766 kg | |
| Weight (Sight Only) | < 0.659 kg |
