RADAR
Multi-mission & Multi-functional
Shibli’s radar solutions offer cuttingedge 2D and 3D capabilities, delivering high-precision target detection, tracking, and classification. With extended range, rapid refresh rates, and multi-target handling, our radars provide a powerful foundation for integrated surveillance and defense systems.
Explore
RADAR
About RADAR
- Pulse Doppler AESA (active electronically scan array) 2D and 3D Radars
- High efficacy in border/perimeter security solutions
- X and S band radars with advance ECCM (electronic countercounter measure) features
- State of the art signal processing algorithms
- Remarkable accuracies and resolutions
- High data rate for integration with close loop systems
- User friendly MMI (man machine interface) with smart BITE
Specifications
RADAR
RADAR
| Parameter | S-Band Radar | X-Band Radar |
|---|---|---|
| Instrumented Range (Km) | 60 | 50 |
| Range (RCS = 0.01 m²) (Km) | 8 | |
| Range (RCS = 0.1 m²) (Km) | 14 | 12 |
| Range (RCS = 1 m²) (Km) | 20 | |
| Elevation Coverage (ft) | 30000 | |
| Range Accuracy (m) | 7.5 | |
| Range Resolution (m) | 30 | |
| Bearing Accuracy (deg) | 0.3 | |
| Bearing Resolution (deg) | 3 | |
| Height Accuracy (deg) | 0.3 | |
| Height Resolution (deg) | 1 | |
| Update Rate (secs) | 1 & 5 | 2 |
Disclosure
The product availability on website is for marketing purpose only and does not guarantee/imply that the device
is available in your country for use/sell/order/other purposes.
